As we approach the 26th anniversary of the 21st century, hardware continues to get cheaper and more powerful. Data centers now operate with terabytes of RAM, a scale that would have been unimaginable not long ago. Yet, as the old saying goes, Memory is never truly infinite.
Cache eviction algorithms have evolved a lot, and there’s no single strategy that fits every need. That’s why we’ve ended up with so many of them.
I came across the SIEVE eviction policy and wanted to see how it really works. The best way to learn, at least for me, is to try building it myself. So I decided to write a cache with SIEVE eviction, using Zig as my language of choice. Let’s see how it goes!
/// The cache object
pub fn Cache(comptime K: type, comptime V: type) type {
return struct {
/// Thread-safe Wrapper over traditional hashmap
inner: map.ChashMap(K, *Node(K, V)),
/// Doubly linkedlist for the eviction
expiry: DoubleLinkedList(K, V),
/// Allocator
allocator: std.mem.Allocator,
/// Eviction policy enum
eviction: EvictionPolicy(K, V),
/// Size of the cache
limit: usize,
/// Optional TTL
ttl: ?i64,
const Self = @This();
}
};
This is our basic cache object. Internally, it uses a doubly linked list to keep track of which
element should be evicted next. Alongside that, we maintain a size to enforce
capacity limits, and a ttl (time-to-live) attribute so entries can expire automatically
after a certain duration.
Now with that settled, let’s walk through what actually happens when
we insert an object into the cache. This is where the behavior of SIEVE starts
to look different from the traditional LRU approach. In LRU, every insert pushes
the item to the back of the queue so it’s treated as the most recently used.
SIEVE, on the other hand, takes a lighter path—placing items at the front and
marking them with a simple visited flag. This small change is what
gives SIEVE its efficiency later when it comes time to evict entries.
Take a look at the code below, whenever we insert an element into the cache if the element is already found LRU moves it to the back to indicate the object was recently used while SIEVE just marks it as visited. A little tweak but it's gonna come in handy later during eviction
pub inline fn insert(
self: Self,
allocator: std.mem.Allocator,
node: ?*Node(K, V),
queue: *DoubleLinkedList(K, V),
key: K,
value: V,
) !?*Node(K, V) {
switch (self) {
.LeastRecentlyUsed => {
if (node) |nonull_node| {
nonull_node.data = value;
queue.moveToBack(nonull_node);
return null;
} else {
const new_node = try Node(K, V).init(key, value, allocator);
const is_pushed = queue.push_back(new_node);
if (is_pushed) {
return new_node;
} else {
new_node.deinit();
return null;
}
}
},
.Sieve => {
if (node) |nonull_node| {
nonull_node.data = value;
nonull_node.visited = true;
return null;
} else {
const new_node = try Node(K, V).init(key, value, allocator);
const is_pushed = queue.push_front(new_node);
if (is_pushed) {
return new_node;
} else {
new_node.deinit();
return null;
}
}
},
}
}
Now that we’ve covered how inserts work, let’s move on to lookups—the
get operation. After all, the whole point of a cache is to serve
as many requests as possible from memory, which means aiming for more cache
hits and fewer misses.
In LRU, every time you fetch an object from the cache, it’s moved to the back of the queue and treated as the most recently used. This means that even an occasional access is enough to keep the object from being evicted, as long as other items don’t crowd the cache beyond its limit.
SIEVE takes a different approach. When you fetch an object, it doesn’t shuffle
the queue like LRU does. Instead, it simply marks the item as visited.
This makes the policy more lightweight: items don’t get artificially promoted
to the “safest” position with every single access, but are still given a chance
to survive eviction if they’re actually used again. In other words, SIEVE
avoids keeping rarely used objects around forever just because they were accessed once.
The idea of tagging recently accessed items with a simple marker isn’t entirely new it comes from the CLOCK eviction policy, which uses reference bits to track whether an item has been accessed recently.
pub inline fn get(
self: Self,
node: ?*Node(K, V),
queue: *DoubleLinkedList(K, V),
) ?V {
switch (self) {
// On every get the node is moved to back in LRU
.LeastRecentlyUsed => {
if (node) |nonull_node| {
queue.moveToBack(nonull_node);
return nonull_node.data;
} else {
return null;
}
},
// SIEVE does not modify the queue, rather it just marks the node as visited
.Sieve => {
if (node) |nonull_node| {
nonull_node.set_visited(true);
return nonull_node.data;
}
return null;
},
}
}
Now that we understand how lookups work, let’s move on to eviction. We’ve already touched on the idea of how items are chosen to be removed, but now it’s time to look at the actual mechanics of how eviction is carried out.
pub inline fn evict(self: Self, ll: *DoubleLinkedList(K, V)) ?K {
switch (self) {
.LeastRecentlyUsed => {
if (ll.front) |front| {
return front.key;
}
return null;
},
.Sieve => {
var hand = ll.cursor orelse ll.back;
while (hand) |node| : (hand = node.prev orelse ll.back) {
if (!node.visited) {
ll.cursor = node.prev;
return node.key;
}
node.visited = false;
}
return null;
},
}
}
Eviction is basically the moment when the cache decides who gets to stay
and who has to go. In LRU, it’s simple — the item that’s been ignored the
longest (sitting at the front of the queue) gets evicted.
SIEVE handles this a little differently. It looks at the item at the front:
if it’s been marked as visited, the cache clears that mark and
gives the item another chance by moving it to the back. If it hasn’t been
touched in a while, it’s shown the door. This way, things you actually use
tend to stick around, and the stale stuff slowly makes its way out.
Well that’s a wrap! If this stuff got you curious, I’ll drop a link to the full repo below. Honestly, the most fun part of writing this wasn’t typing out the blog—it was building SIEVE myself and seeing it click. I really believe the best way to learn is by rolling up your sleeves and trying it out. It scratches that curiosity itch in a way just reading never does.
Oh also I am new to zig so if you are angry at how I wrote the code, I totally understand :p
